Flanges
We are one of the leading Manufacturers, Suppliers & Exporters of Pipes & Tubes in different shapes and sizes and with different specifications as per the customers’ requirement. These Pipes & Tubes are characterized by high durability, resistance to corrosion, flawless finish and complete reliability in service.
Our complete range is stringently tested by our well equipped testing unit, to ensure their compliance with international quality norms. These Pipes & Tubes are used in various industries like Oil & gas, Petrochemical, Pharmaceutical, Fertilizers, Construction, Food, Power and Instrumentation.
Flanges Specification :-
| Dimensions |
: |
ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings |
| Size |
: |
1/2" (15 NB) to 48" (1200NB) |
| Class |
: |
150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc. |
| DIN |
|
DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636,DIN2637, DIN2638, DIN2673 |
| BS |
: |
BS4504 , BS4504, BS1560, BS10 |
| Flange Face Type |
: |
Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
Stainless Steel Flanges Specification
Size : ½” to 48”
Stainless Steel : ASTM A182 , A240 F 202, 304, 304L, 304H, 316, 316Ti, 316H, 316L, 316LN, 309S, 309H, 310S, 310H,317, 317L, 321, 321H, 347, 347H, 201, 202, 904L
Duplex Steel Flanges Specification
Range : 15 NB UP TO 600 NB IN
Duplex Steel : ASTM A182, A240 UNS F 44, F 45, F51, F 53, F 55, F 60, F 61
Super Duplex Steel Flanges Specification
Size : 1/8" NB TO 24" NB
Grade : ASTM A182 / ASME SA182 UNS NO. S32750 / S32760 / S32950
Carbon Steel Flanges Specification
Size : 15 NB UP TO 600 NB IN
Carbon Steel : ASTM / ASME A 105, A53 GR B, A106GR B, API5L GRADE B, API 5L, GRX42 / 46 / 52 / 56 / 60 / 65 / 70, A333 GR 1/GR 3/GR 6, A/SA 672 GR 8C60/C70 etc..
Alloy Steel Flanges Specification
Size : 15 NB UP TO 600 NB IN
Alloy Steel : ASTM / ASME A182 GR F 5, F 9, F 11, F 12, F 22, F 91.
Inconel Flanges Specification
Size : 1/2 inch - 48 inch (15mm - 1200mm)
Inconel : ASTM SB564, SB160, SB472, SB162 Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750, Incoloy 800, incoloy 825, Incoloy 925, Incoloy a-286
Monel Flanges Specification
Range : 1/2” NB to 60” NB
Monel : ASTM / ASME SB164 Monel 400 (N04400), Monel 500 (N05500)
Hastelloy Flanges Specification
Range : 1/2"NB to 12"NB
Hastelloy : ASTM SB564, SB160, SB472, SB162 Hastelloy C22, Hastelloy C276, Hastelloy C4, Hastelloy B, Hastelloy C-2000
Cupro Nickel Alloy Flanges Specification
Range : 15 NB UP TO 600 NB IN
Cupro Nickel Alloy : ASTM SB61, SB62, SB151, SB152 UNS No. C70600 (Cu-Ni 90/10), C71500 (Cu-Ni 70/30), UNS No. C10100, 10200, 10300, 10800, 12000, 12200
Nickel Alloy Flanges Specification
Range : 15 NB UP TO 600 NB IN
Nickel Alloy : ASTM SB564, SB160, SB472, SB162 Nickel 200 (N02200), Nickel 201 (N02201), Nickel 205 (N02205)
