Forged socket weld fittings
We are one of the leading Manufacturers, Suppliers & Exporters of Pipes & Tubes in different shapes and sizes and with different specifications as per the customers’ requirement. These Pipes & Tubes are characterized by high durability, resistance to corrosion, flawless finish and complete reliability in service.
Our complete range is stringently tested by our well equipped testing unit, to ensure their compliance with international quality norms. These Pipes & Tubes are used in various industries like Oil & gas, Petrochemical, Pharmaceutical, Fertilizers, Construction, Food, Power and Instrumentation.
Forged socket weld fittings Specification :-
| Dimensions |
: |
ASME 16.11, MSS SP-79, MSS SP-95, 83, 95, 97, BS 3799 |
| Size |
: |
1/8" NB TO 4" NB |
| Pressure Class |
: |
2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type |
|
Socketweld Fittings, Screwed-Threaded Fittings |
| Form |
: |
45 deg Elbow, 90 deg Elbow, Tee, Cross, Coupling, Half Coupling, Cap, Hex Nipple etc. |
Stainless Steel Forged Fittings Specification
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Stainless Steel : ASTM / ASME SA182 F202, 304, 304L, 304H, 309H, 310H, 316, 316H, 316L , 316 LN, 317, 317L, 321, 321H, 347, 347H, 904L
Duplex Steel Forged Fittings Specification
Range : 1/2"NB TO 4"NB IN
Duplex Steel : ASTM A182 / ASME SA182 F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61.
Super Duplex Steel Forged Fittings Specification
Size : 1/2"NB TO 4"NB IN(Socketweld & Screwed-Threaded)
Super Duplex Steel : ASTM A182 / ASME SA182 UNS NO. S32750 / S32760 / S32950
Carbon Steel Forged Fittings Specification
Size :½”NB to 48″NB in
Carbon Steel : ASTM A105 / A694 / A350 LF3 / A350 F42 / F46 / F52 / F56 / F60 / F65 / F70, LF2. A420 WPL3 / A420 WPL6
Alloy Steel Forged Fittings Specification
Size :½”NB to 48″NB in
Alloy Steel :ASTM / ASME A182 GR F5, F9, F11, F12, F22, F91.
Inconel Forged Fittings Specification
Size :1/8" TO 4"
Inconel / Incoloy :ASTM / ASME SB 564 / 160 / 472 Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750, Incoloy 800, incoloy 825, Incoloy 925, Incoloy a-286
Monel Forged Fittings Specification
Range : 1/8" TO 4"
Monel : ASTM / ASME SB 564 / 160 / 472 Monel 400 (N04400), Monel 500 (N05500)
Hastelloy Forged Fittings Specification
Range : 1/8" TO 4"
Hastelloy : ASTM / ASME SB 564 / 160 / 472 Hastelloy C22, Hastelloy C276, Hastelloy C4, Hastelloy B, Hastelloy C-2000
Cupro Nickel alloy Forged Fittings Specification
Range : ½”NB to 24”NB in
Cupro Nickel Alloy : ASTM B122, B171, B466, B467 UNS No. C70600 (Cu-Ni 90/10), C71500 (Cu-Ni 70/30), UNS No. C 10100, 10200, 10300, 10800, 12000, 12200
Nickel Alloy Forged Fittings Specification
Range : 1/2"NB TO 4"NB IN
Nickel Alloy : ASTM / ASME SB564 / 160 / 472 Nickel 200 (N02200), Nickel 201 (N02201), Nickel 205 (N02205)
